LiuGong
LT22JE
LT22JE Telescopic Boom Lift (Electric) with a max working height of 23.8 m, max operating range of 16.3 m, and platform load of 454 kg/300 kg.
RFQ basis
Read MoreSpecifications
| Max.Working Height | 23.8 m |
|---|---|
| Max.Operating Range | 16.3 m |
| Overall Width(Stowed) | 2.42 m |
| Overall Length(Transport) | 9.5 m |
| Overall Height(Transport) | 2.27 m |
| Platform Size(L×W×H) | 2.4×0.9×1.1 m |
| Platform Load(Unrestricted/Restricted) | 454kg/300 kg |
| Max.Working Slope | X-5°/Y-5° |
| Drive Steering Type | 4WD×2WS |
| Charger | 48V/80A |
| Max.Platform Height | 21.8 m |
| Overall Length(Stowed) | 9.5 m |
| Overall Height(Stowed) | 2.47 m |
| Overall Width(Transport) | 2.28 m |
| Turntable Tailswing(Raised) | 1.65 m |
| Tyres | 385/65-24（Solid off-road tyre） |
| Gradeability | 40 % |
| Turret Rotation | 360°(Continuous) |
| Battery（Lithium） | 48V/460Ah |
| Hydraulic Oil Tank | 100 L |
Product Detail
Safe And Reliability: Standard dual channel sensor, safe and reliable; electric emergency power systems provide more security; the protection level of components of the whole machine is above IP65, the protection level is high. Intelligent And Efficient: Composite action, intelligent and efficient; electronic differential combined with suspending axle technology for better trafficability; the turntable rotates 360 degrees continuously with small tail, which is suitable for narrow space operation; four wheel strong AC electric drive, climbing capacity up to 45%, strong trafficability; high-power charger, large-capacity power battery, fast charging, ultra-long endurance. Energy Saving And Comfort: Self-weight decrease through the booms, energy saving and stable; automatic deceleration at the action limit position, stable action, small shaking; optimize the electric control algorithm with the load sensitive hydraulic system to achieve accurate power output. Green And Environmental Protection: Pure electric power, low use and maintenance cost, high return on investment; green and environmental protection, no emission, low noise, meet indoor and outdoor working conditions.
